Production Capacity
Available Configurations
Standard Warranty
Countries Installed
Available Models
Choose the right capacity for your project requirements. 10 Models
HZS240 Stationary Concrete Batching Plant
HZS240 Stationary Concrete Batching Plant
High-performance stationary plant with 240 m³/h output. Features the powerful JS4000 twin-shaft mixer, intelligent weighing system, and fully enclosed environmental design. Built for large-scale infrastructure and commercial concrete production.
HZS75 Stationary Concrete Batching Plant
HZS75 Stationary Concrete Batching Plant
High-performance stationary plant with 75 m³/h output. Features the powerful JS1500 twin-shaft mixer, intelligent weighing system, and fully enclosed environmental design. Built for large-scale infrastructure and commercial concrete production.
HZS60 Stationary Concrete Batching Plant
HZS60 Stationary Concrete Batching Plant
High-performance stationary plant with 60 m³/h output. Features the powerful JS1000 twin-shaft mixer, intelligent weighing system, and fully enclosed environmental design. Built for large-scale infrastructure and commercial concrete production.
HZS90 Stationary Plant
HZS90 Stationary Plant
HZS90 Stationary Plant - Stationary Concrete Batching Plant. High-quality manufacturing direct from Xingye Machinery.
HZS50 Stationary Concrete Batching Plant
HZS50 Stationary Concrete Batching Plant
High-performance stationary plant with 50 m³/h output. Features the powerful JS1000 twin-shaft mixer, intelligent weighing system, and fully enclosed environmental design. Built for large-scale infrastructure and commercial concrete production.
HZS120 Stationary Environmental Batching Plant
HZS120 Stationary Environmental Batching Plant
Heavy-duty 120 m³/h stationary concrete batching plant. Features a JS2000 twin-shaft mixer and fully enclosed pulse dust collection. Designed for high-standard commercial concrete and large-scale infrastructure with milligram-level precision.
HZS180 Stationary Concrete Batching Plant
HZS180 Stationary Concrete Batching Plant
High-performance stationary plant with 180 m³/h output. Features the powerful JS3000 twin-shaft mixer, intelligent weighing system, and fully enclosed environmental design. Built for large-scale infrastructure and commercial concrete production.
HZS60
HZS60 Stationary Concrete Batching Plant
High-performance stationary plant with 60 m³/h output. Features the powerful JS1000 twin-shaft mixer, intelligent weighing system, and fully enclosed environmental design. Built for large-scale infrastructure and commercial concrete production.
HZS90
HZS90 Stationary Environmental Batching Plant
90 m³/h capacity stationary plant. Features JS1500 mixer and continuous belt feeding. Perfectly balances footprint and output. Environmentally enclosed design with smart anti-fraud control system.
HZS120
HZS120 Stationary Plant
HZS120 Stationary Plant - Stationary Concrete Batching Plant. High-quality manufacturing direct from Xingye Machinery.
Model Comparison
| Parameter | HZS90 | HZS120 Stationary Environmental Batching Plant | HZS120 | HZS180 Stationary Concrete Batching Plant |
|---|---|---|---|---|
| Theoretical Productivity | 90 m³/h | 120 m³/h | - | - |
| Mixer Model | JS1500 (1.5 m³ per batch) | JS2000 (Twin-Shaft Forced) | - | - |
| Feeding System | Heavy-duty Trough Belt Conveyor | - | - | - |
| Mixer Motor Power | 2 × 30 kW | 2 × 37 kW | - | - |
| Aggregate Bins | 3-4 Bins (Cumulative/Independent Weighing) | 4 Bins (Independent Weighing) | - | - |
| Max Aggregate Size | ≤ 80 mm | ≤ 80 mm | - | - |
| Standard Discharge Height | 4.2 m | 4.2 m (Perfect for transit mixers) | - | - |
| Weighing Accuracy | Aggregate ±2% / Powder & Liquids ±1% | - | - | - |
| Total Installed Power | ~ 145 kW | - | - | - |
| Aggregate Accuracy | - | 5000 kg ±2% | - | - |
| Cement Accuracy | - | 1500 kg ±1% | - | - |
| Fly Ash Accuracy | - | 800 kg ±1% | - | - |
| Water & Additive Accuracy | - | Water 700 kg ±1% / Additive 50 kg ±1% | - | - |
| Footprint (Linear Type) | - | ~ 64m × 17m × 12.5m | - | - |
| Footprint (L-Type) | - | ~ 47m × 21m × 12.5m | - | - |
| Theoretical capacity | - | - | 120m³/h | 180m³/h |
| Model of mixer | - | - | JS2000 | JS3000 |
| Mixing motor power | - | - | 2×37kW | 2×55kW |
| Number of kinds of aggregate | - | - | 4 | 4 |
| Max. aggregate sizes | - | - | ≤80mm | ≤80mm |
| Discharge height | - | - | 4.2m | 4.2m |
| Weighing accuracy - Aggregate | - | - | 5000kg | 8000kg |
| Weighing accuracy - Cement | - | - | 1500kg | 1800kg |
| Weighing accuracy - Coal ash | - | - | 800kg | 1000kg |
| Weighing accuracy - Water | - | - | 700kg | 800kg |
| Weighing accuracy - Additive | - | - | 50kg | 80kg |
| Overall dimension (L×W×H) - Inline type | - | - | 64000 × 17000 × 12484mm | 74000 × 13540 × 11850mm |
| Overall dimension (L×W×H) - L type | - | - | 47000 × 21000 × 12484mm | 53800 × 24500 × 11850mm |
Designed for Real-World Project Conditions
Models Available
Industrial-Grade Output for Large-Scale Projects
HZS series stationary plants deliver consistent, high-volume concrete for ready-mix producers and major infrastructure contractors. Twin-shaft JS mixers ensure uniform mixing at every batch from 25 to 240 m³/h.
Global Installation Cases
120m³ Stationary Plant in Myanmar
What Our Clients Say
The HZS120 plant has been running 18 hours a day for 2 years. Zero major breakdowns. The control system is incredibly precise, saving us 5% on cement costs.
We replaced our old Italian mixers with Xingye's Twin-Shaft JS3000. The mixing homogeneity is identical, but the maintenance cost is 40% lower.
Installation was surprisingly fast. The engineers arrived on time and had the 60m³/h plant running in just 10 days. Great training for our local team.
We need equipment that works in -20°C winters. Xingye's heating system and insulated cladding performed perfectly. A reliable partner for harsh climates.
HZS Stationary Concrete Batching Plant Series FAQ
1. What foundation is required for an HZS plant?
HZS stationary plants require a reinforced concrete foundation. Our engineers provide foundation drawings tailored to your soil bearing capacity. Typical foundation preparation takes 7–14 days.
2. What is the mixing cycle time for the HZS120?
The HZS120 completes one mixing cycle in approximately 72 seconds using a JS2000 twin-shaft mixer, achieving a real-world output of approximately 90–100 m³/h under standard conditions.
3. How many cement silos can be connected?
Standard configurations include 1–2 cement silos. Up to 4 silos can be connected with extended piping. Silo capacities range from 100T to 1000T depending on project storage requirements.
4. Does the control system support multiple mix designs?
Yes. The PLC system stores 50+ mix recipes, supports automatic and manual modes, generates production reports, and can integrate with weighbridge or ERP systems via Modbus.
5. What is the delivery time for an HZS120?
Standard HZS120 plants are completed and ready to ship within 30–45 days of order confirmation. Custom configurations may require 45–60 days.
Request a Quote
Tell us your capacity needs — we'll recommend the right equipment and send a detailed proposal within 24 hours.
